  3. MRCOOL 36K BTU Downflow Two-Stage CuNi Coil - Right Return, GCHPD036TGTANXR

MRCOOL 36K BTU Downflow Two-Stage CuNi Coil - Right Return, GCHPD036TGTANXR

Model: GCHPD036TGTANXR
$5,903.00
$5,903.00 $7,105.00
-17%
Shipping calculated at checkout.

Financing Options

This item is in stock! Estimated Arrival: Oct 17 to Oct 23

$5,903.00
$5,903.00 $7,105.00

What's Included

BETTER TOGETHER

DESCRIPTION

36K BTU Downflow Two-Stage 230V 1-Phase 60Hz CuNi Coil Right Return

Features:

  • Qualifies for federal tax credit, and other incentives
  • Highest energy efficiency in its class
  • Safety high and low pressure switches
  • Quiet operation
  • Full featured sinusoidal eon motor control technology
  • Insulated sloped stainless steel drain pan
  • Advanced unit control board with diagnostic LEDs
  • Double O-ring water connections
  • Easy service access
  • Optional domestic water pre-heating
  • Made in the USA
  • 10 year compressor warranty

    SPECIFICATIONS & DIMENSIONS

    • Product Dimensions: 25.75"W x 32"D x 56"H
    • Product Weight: 350 lbs
    • EER: Ground Water (FULL) 27.20 / Ground Loop (FULL)17.86
    • EER Part Load: Ground Water (PART) 35.70 / Ground Loop (PART) 25.84
    • COP 47: Ground Water (FULL) 5.30 / Ground Loop 4.40 (FULL)
    • COP 47 Part Load: Ground Water (PART) 5.60 / Ground Loop 4.80 (PART)
    • HSPF: Ground Water Fluid Flow Rate | COOLING: (PART) 8 - 9 (FULL) / HEATING: (PART) 8 - 9 (FULL)
    • AFUE: Ground Loop Fluid Flow Rate | COOLING: (PART) 8 - 9 (FULL) / HEATING: (PART) 8 - 9 (FULL)
    • CFM: COOLING (PART) 1150 - 1350 (FULL) / HEATING (PART) 1100 - 1100 (FULL)
    • Tonnage: 3
    • Cooling Capacity: Ground Water (PART) 33000 - 43000 (FULL) / Ground Loop (PART) 30300 - 39000 (FULL)
    • Heating Capacity: Ground Water (PART) 27500 - 38000 (FULL) / Ground Loop (PART) 24000 - 26900 (FULL)
    • Voltage: 230V/60Hz/42A
    • Phase: 1
    • Cycle: 60
    • Stage: Two-Stage
    • Max Fuse Breaker: 42.1(W/O Desupe
    • Min Circuit Ampacity: 26.4
    • Configuration: Right Return Downflow
    • Color: Gray
    • Max Coverage Area: 1500
    • Refrigerant Type: R-410A
    • Compressor Motor Type: Scroll
    • Blower Motor Type: Axial Flux (No Shaft) BLA
    • Blower Motor HP: 3/4
    • Filter Type: Replaceable
    • Contains: Electronics // Chemicals // Aerosol // Compressed Gas
    • Proposition 65 Warning: Yes
    • Certifications: ETL Listed // Energy Star // AHRI
    • Warranty: Registered 10 Year Parts Warranty
