MRCOOL 24K BTU Downflow Two-Stage CuNi Coil - Right Return, GCHPD024TGTANXR

Model: GCHPD024TGTANXR
$5,766.00
$5,766.00 $6,959.00
-17%
Shipping calculated at checkout.

This item is in stock! Estimated Arrival: Mar 22 to Mar 28

Buy Now, Pay Later

$5,766.00
$5,766.00 $6,959.00

What's Included

BETTER TOGETHER

DESCRIPTION

24K BTU Downflow Two-Stage 230V 1-Phase 60Hz CuNi Coil Right Return

Features:

  • Qualifies for federal tax credit, and other incentives
  • Highest energy efficiency in its class
  • Safety high and low pressure switches
  • Quiet operation
  • Full featured sinusoidal eon motor control technology
  • Insulated sloped stainless steel drain pan
  • Advanced unit control board with diagnostic LEDs
  • Double O-ring water connections
  • Easy service access
  • Optional domestic water pre-heating
  • Made in the USA
  • 10 year compressor warranty

    SPECIFICATIONS & DIMENSIONS

    • Product Dimensions: 25.75"W x 32"D x 56"H
    • Product Weight: 325 lbs
    • EER: Ground Water (FULL) 27.40 / Ground Loop (FULL) 17.95
    • EER Part Load: Ground Water (PART) 36.50 / Ground Loop (PART) 25.93
    • COP 47: Ground Water (FULL) 5.40 / Ground Loop 4.20 (FULL)
    • COP 47 Part Load: Ground Water (PART) 5.50 / Ground Loop 4.70 (PART)
    • HSPF: Ground Water Fluid Flow Rate | COOLING: (PART) 7 - 8 (FULL) / HEATING: (PART) 7 - 8 (FULL)
    • AFUE: Ground Loop Fluid Flow Rate | COOLING: (PART) 7 - 8 (FULL) / HEATING: (PART) 7 - 8 (FULL)
    • CFM: COOLING (PART) 850 - 1000 (FULL) / HEATING (PART) 800 - 950 (FULL)
    • Tonnage: 2
    • Cooling Capacity: Ground Water (PART) 23000 - 29000 (FULL) / Ground Loop (PART) 21900 - 27000 (FULL)
    • Heating Capacity: Ground Water (PART) 19000 - 25700 (FULL) / Ground Loop (PART) 16500 - 18500 (FULL)
    • Voltage: 230V/60Hz/34A
    • Phase: 1
    • Cycle: 60
    • Stage: Two-Stage
    • Max Fuse Breaker: 34.0(W/O Desupe
    • Min Circuit Ampacity: 21.9
    • Configuration: Right Return Downflow
    • Color: Gray
    • Max Coverage Area: 1,000 square feet
    • Refrigerant Type: R-410A
    • Compressor Motor Type: Scroll
    • Blower Motor Type: Axial Flux (No Shaft) BLA
    • Blower Motor HP: 3/4
    • Filter Type: Replaceable
    • Contains: Electronics // Chemicals // Aerosol // Compressed Gas
    • Proposition 65 Warning: Yes
    • Certifications: ETL Listed // Energy Star // AHRI
    • Warranty: Registered 10 Year Parts Warranty
