MRCOOL DIY® 5th Gen 18,000 BTU Multi-Zone Mini Split Condenser 230V, DIY-MULTI3-18HP230D-O

Model: DIY-MULTI3-18HP230D-OMore from MRCOOL
Skip to product information
Regular price $1,555.00
Sale price $1,555.00 Regular price $1,899.00
Save $344
Shipping calculated at checkout.
BTU: 18,000
In Stock · Delivers Nov 26-30 (Est.)
Free Curbside Shipping

MRCOOL DIY® 5th Gen 18,000 BTU Multi-Zone Mini Split Condenser 230V, DIY-MULTI3-18HP230D-O

Regular price $1,555.00
Sale price $1,555.00 Regular price $1,899.00

Free shipping

Ask about this product Get an answer with Appliance AI™
AI-generated from product data and store information. Responses may not always be accurate. For any clarifications, talk to our team.

Product Overview

  • DIY Installation

  • Voltage: 208-230V

Collapsible content

DESCRIPTION

Discover the 5th Generation MRCOOL® DIY® 18k BTU Multi-Zone Ductless Mini Split Condenser — the ultimate blend of performance, innovation, and convenience. This powerful system is designed for easy, do-it-yourself installation without the need for an HVAC technician, saving you time and money. With outstanding energy efficiency and smart connectivity, it offers a customized comfort experience for up to three rooms with a combined 750 square feet of space.

  • DIY Installation: Designed with patented pre-charged Quick Connect® line sets, this unit allows you to install the system yourself, eliminating the need for professional HVAC assistance.
  • High Efficiency: Achieves an impressive SEER2 rating of 23.9 and an HSPF2-4 rating of 10, ensuring lower energy consumption and reduced utility costs.
  • Multi-Zone Capability: Supports up to three air handlers, making it perfect for heating and cooling multiple rooms with independent comfort control.
  • Eco-Friendly Refrigerant: Uses R-454B, an environmentally friendly and energy-efficient refrigerant that enhances system sustainability and performance.
  • Smart Control: Compatible with Amazon Alexa and Google Home through the Smart HVAC app, allowing voice commands, scheduling, and temperature control from your smartphone.
  • Comprehensive Warranty: Includes a 7-year compressor warranty, 5-year parts warranty
  • Compact Power: Efficiently heats and cools up to 750 square feet, ideal for bedrooms, offices, or smaller living spaces.
  • Quick Connect Line Sets Sold Separately: Choose the length you need for your installation setup; each set comes pre-charged and ready to connect.

SPECIFICATIONS & DIMENSIONS

  • DIMENSIONS
  • Dimensions: 35.04" W x 13.46" D x 29.53" H
  • Weight: 101.63 lbs
  • CAPACITY & PEFORMANCE
  • Maximum Zones: 3
  • Cooling Capacity: 18,000 BTU
  • SEER2: 23.9
  • EER2: 13
  • Heating Capacity: 18,000 BTU
  • HSPF2-4: 10
  • HSPF2-5: 7.8
  • Outdoor Noise Level: 60 dB(A)
  • Outdoor Operating Temperature: Cooling: -13°F to 122°F//Heating: -13°F to 75°F
  • ELECTRICAL REQUIREMENTS
  • Voltage: 208-230V
  • Phase: 1
  • Cycle: 60 Hz
  • Max Fuse Breaker: 20A
  • Min Circuit Ampacity: 16A
  • REFRIGERANT & PIPING
  • Refrigerant Type: R-454B
  • Refrigerant Volume: 61.73 oz
  • Liquid Line Size: 1/4"
  • Suction Line Size: 3/8"
  • Max Line Set Length: 172.2 ft.
  • FEATURES
  • Inverter: DC
  • Compressor Type: Rotary
  • Fan Only Option: Yes
  • Quiet Mode: Yes
  • Auto Cool: Yes
  • Wifi Compatibility: Yes
  • App Compatibility: Yes
  • Works with IOS: Yes
  • Works with Android: Yes
  • CERTIFICATIONS & WARRANTY
  • Certifications: Energy Star Certified, UL Listed, ETL Listed, AHRI Certified
  • Warranty: 7 Years Compressor // 5 Years Parts

INSTALLATION & GUIDES

SHIPPING POLICY

Free Curbside Delivery
MRCOOL orders include free curbside delivery via FedEx Ground, UPS, FedEx Freight, or the most effective and affordable option for your order. Please note that delivery is to the curbside only - be sure to arrange for assistance if needed, as the carrier will not bring items inside your home.

Tracking & Delivery Scheduling
In most cases, you will receive tracking details 3-5 business days after you place your order. When the tracking number is sent, please allow 1-2 business days for the tracking number to populate details.

See our full Shipping Policy here.

RETURN POLICY

MRCOOL returns must be requested within 30 days of your delivery date. We are unable to process returns submitted after this period. Products must be unused, uninstalled, and in their original packaging, including the box and pallet, to qualify for a return.

Restocking Fee
Please note, a 30% restocking fee will be applied to all approved returns.

Non-Returnable Items
Items that cannot be returned: Lineguards, wall mounts, linesets, couplers. Accessories are not returnable. This includes, but is not limited to, any add-ons, trim, parts and accessory items sold with or for the product.

See our full Return Policy here.

About MRCOOL

Industry's Only DIY Mini Split Ductless System!

Upgrade your home’s heating and cooling with the MRCOOL DIY Mini Split, designed for hassle-free installation and superior energy efficiency. With its innovative patented pre-charged line sets, you can enjoy year-round comfort without the need for professional help. Ideal for homeowners, the MRCOOL DIY series offers customizable climate control with a high SEER rating, ensuring you save on energy bills while maintaining optimal comfort. Key features include a variable-speed inverter compressor, wireless control through smart devices, and compatibility with Amazon Alexa and Google Assistant for seamless home automation. Available in various sizes, this system provides reliable and quiet operation, perfect for bedrooms, living rooms, or any space in your home. Backed by an industry-leading warranty, the MRCOOL DIY Mini Split is the perfect solution for homeowners seeking powerful performance, ease of use, and long-term savings.
