  2. MRCOOL 5th Gen Advantage 24,000 BTU Single Zone Mini Split Complete System with 16ft. Line Set 230V (HVAC Technician Required), A-24-HP-230D-O

MRCOOL 5th Gen Advantage 24,000 BTU Single Zone Mini Split Complete System with 16ft. Line Set 230V (HVAC Technician Required), A-24-HP-230D-O

Model: A-24-HP-230D-OMore from MRCOOL
$1,462.00
$1,462.00 $1,700.00
Save $238
Shipping calculated at checkout.
Condenser BTU: 24,000
Voltage: 230V
In Stock · Delivers Nov 23-27 (Est.)
Free Curbside Shipping

MRCOOL 5th Gen Advantage 24,000 BTU Single Zone Mini Split Complete System with 16ft. Line Set 230V (HVAC Technician Required), A-24-HP-230D-O

$1,462.00
$1,462.00 $1,700.00

Free shipping
Ask about this product Get an answer with Appliance AI™
AI-generated from product data and store information. Responses may not always be accurate. For any clarifications, talk to our team.

Product Overview

  • Zones: 1

  • HVAC Tech Required

  • Voltage: 208-230V

  • Outdoor Operating Temp (Cool): 5°F to 122°F

  • Outdoor Operating Temp (Heat): 5°F to 86°F

What's Included

DESCRIPTION

MRCOOL 5th Gen Advantage 24,000 BTU Mini-Split delivers efficient climate control for spaces up to 1000 sq. ft. This ductless system features eco-friendly R-454B refrigerant, impressive SEER2 rating of 18.7, and built-in Wi-Fi control. Includes 16ft line set and corrosion-resistant Gold Fin® condenser. Professional HVAC installation required. Ideal for year-round comfort with minimal energy consumption.

  • Gold Fin® Condenser: Corrosion-resistant design ideal for coastal environments.
  • R-454B Refrigerant: Eco-friendly with 80% lower GWP than R-410A.
  • High Efficiency Ratings: Up to 18.7 SEER2 and 9.3 HSPF2-4 for energy savings.
  • Smart Controls: Built-in Wi-Fi supports Google Assistant & Amazon Alexa.
  • Remote + Follow Me® Mode: Automatically adjusts temperature based on your location.
  • Quiet Operation: Indoor noise levels as low as 21.5 dB(A).
  • Coverage Area: Effectively cools/heats rooms up to 1000 sq. ft.
  • Timer Mode + Leak Detection: Intelligent operation with safety and savings in mind.
  • Certified & Listed: AHRI Certified, NEEP ccASHP Listed, CEE Tier 1 (North).
  • Warranty & Support: 1-year parts, 2-year compressor, 1-year remote warranty; optional Lifetime compressor coverage with MRCOOL® Care enrollment.

SPECIFICATIONS & DIMENSIONS

  • DIMENSIONS
  • Condenser Dimensions: 35.04" W x 13.46" D x 26.5" H
  • Air Handler Dimensions: 42.52" W x 8.9" D x 13.19" H
  • Condenser Weight: 94.58 lbs
  • Air Handler Weight: 30.64 lbs
  • CAPACITY & PERFORMANCE
  • Zone Capacity: 1
  • Cooling Capacity: 24,000 BTU
  • Outdoor Operating Temperature (Cooling): 5°F - 122°F
  • EER2: 10
  • SEER2: 18.7
  • Heating Capacity: 24,000 BTU
  • Outdoor Operating Temperature (Heating): 5°F - 75°F
  • HSPF2-4: 9.3
  • HSPF2-5: 7.3
  • Coverage Area: Up to 1000 sq. ft. // Consider factors like ceiling height, insulation, sunlight exposure, and number of occupants.
  • Outdoor Noise Level: 59.5 dB(A)
  • Indoor Noise Level (Hi/Mi/Lo): 54.0/45.0/41.5/27.0/21.5 dB(A)
  • ELECTRICAL REQUIREMENTS
  • Voltage: 208-230 V
  • Phase: 1
  • Cycle: 60 Hz
  • Max Fuse Breaker: 20A
  • Min Circuit Ampacity: 19A
  • REFRIGERANT & PIPING
  • Refrigerant Type: R-454B
  • Refrigerant Volume: 53.62 oz
  • Liquid Line Size: 3/8"
  • Suction Line Size: 5/8"
  • Max Line Set Length: 164 ft.
  • FEATURES
  • Inverter: DC
  • Compressor Type: Rotary
  • Wifi Compatibility: Yes
  • App Compatibility: Yes
  • Works with IOS: Yes
  • Works with Android: Yes
  • Remote Control Included: Yes
  • CERTIFICATIONS & WARRANTY
  • Certifications: UL Listed, CSA Listed, ETL Listed, AHRI Certified
  • Warranty: 1-year parts, 2-year compressor, 1-year remote warranty; optional Lifetime compressor coverage with MRCOOL® Care enrolment.

INSTALLATION & GUIDES

File icon
Product Brochure PDF
File icon
Installation Manual PDF
File icon
Energy Guide PDF
File icon
AHRI Certificate PDF
File icon
Performance Specs PDF
File icon
Warranty Document PDF

SHIPPING POLICY

Free Curbside Delivery
MRCOOL orders include free curbside delivery via FedEx Ground, UPS, FedEx Freight, or the most effective and affordable option for your order. Please note that delivery is to the curbside only - be sure to arrange for assistance if needed, as the carrier will not bring items inside your home.

Tracking & Delivery Scheduling
In most cases, you will receive tracking details 3-5 business days after you place your order. When the tracking number is sent, please allow 1-2 business days for the tracking number to populate details.

See our full Shipping Policy here.

RETURN POLICY

MRCOOL returns must be requested within 30 days of your delivery date. We are unable to process returns submitted after this period. Products must be unused, uninstalled, and in their original packaging, including the box and pallet, to qualify for a return.

Restocking Fee
Please note, a 30% restocking fee will be applied to all approved returns.

Non-Returnable Items
Items that cannot be returned: Lineguards, wall mounts, linesets, couplers. Accessories are not returnable. This includes, but is not limited to, any add-ons, trim, parts and accessory items sold with or for the product.

See our full Return Policy here.

Accessories

You May Also Like

About MRCOOL

Industry's Only DIY Mini Split Ductless System!

Upgrade your home’s heating and cooling with the MRCOOL DIY Mini Split, designed for hassle-free installation and superior energy efficiency. With its innovative patented pre-charged line sets, you can enjoy year-round comfort without the need for professional help. Ideal for homeowners, the MRCOOL DIY series offers customizable climate control with a high SEER rating, ensuring you save on energy bills while maintaining optimal comfort. Key features include a variable-speed inverter compressor, wireless control through smart devices, and compatibility with Amazon Alexa and Google Assistant for seamless home automation. Available in various sizes, this system provides reliable and quiet operation, perfect for bedrooms, living rooms, or any space in your home. Backed by an industry-leading warranty, the MRCOOL DIY Mini Split is the perfect solution for homeowners seeking powerful performance, ease of use, and long-term savings.

See more about MRCOOL
W
Wade will

Are the lines in this unit pre charged

Premium Home Source

Hi Wade, thank you for getting in touch. The included 16 ft line set is not pre charged. This system is part of MRCOOL’s Advantage series and requires a licensed HVAC technician to properly vacuum the lines and charge the system during installation. It is different from MRCOOL DIY systems that include pre charged quick connect lines. For further assistance, contact our product experts at (800) 805-7102 or [email protected]

j
jimmie

is it pre-loaded with refrigerant

Premium Home Source

Hi, thank you for getting in touch.

The MRCOOL Advantage system is not pre-charged and requires installation by a licensed HVAC technician. If you’re looking for a pre-charged, DIY option, we recommend the MRCOOL DIY Single Zone systems here: https://www.premiumhomesource.com/collections/mrcool-diy-single-zone-mini-splits.

If you need more assistance, please contact our product experts at (800) 805-7102 or [email protected]

2
2400btu 230d

I assume this unit is a heat and a/,,c unit.
Also, if i buy 2 can I get a discount?

Premium Home Source

Hi, thank you for getting in touch.
This mini split is indeed a system that can heat or cool. If you purchase 2 or more units, we are happy to offer you a discount. Please contact our product experts at (800) 805-7102 or [email protected].
