BHI 12,000 BTU 19 SEER2 Ductless Mini Split Air Conditioner with Heat Pump 115V with 13 ft. or 25ft. Line Set, BHI-CH-12K115V-US

Model: BHI-CH-12K115V-US-A
$750.00 - $840.00
Shipping calculated at checkout.

Buy Now, Pay Later

no WiFi
no WiFi
with WiFi
13 ft
13 ft
25 ft
Regular price $750.00
Sale price $750.00 Regular price $900.00
-17%

This item is in stock! Estimated Arrival: Jun 05 to Jun 08

Regular price $750.00
Sale price $750.00 Regular price $900.00

Product Overview

  • Zones: 1

  • Covers 600 sq ft.

  • HVAC Tech Required

  • Voltage: 115V

Collapsible content

BETTER TOGETHER

DESCRIPTION

Upgrade your home’s comfort and energy efficiency with the BHI 12,000 BTU Mini Split Air Conditioner and Heat Pump. Engineered for year-round performance, this ductless system delivers powerful cooling and reliable heating for rooms up to 600 sq. ft. Featuring a high-efficiency 19 SEER2 rating, advanced inverter technology, and customizable comfort modes, it's the perfect climate control solution for bedrooms, living rooms, offices, and more.

Whether you're battling summer heat or winter chill, the BHI mini split is designed to maintain consistent temperatures while keeping energy costs low. With smart airflow design, intuitive features like I-Feel and I-Set, and self-cleaning technology, this system ensures healthier air and effortless operation—all in a sleek, wall-mounted unit.

  • 12,000 BTU Cooling & Heating Capacity: Effectively conditions spaces up to 600 sq. ft. with 1-ton performance.
  • High Energy Efficiency: 19 SEER2 rating for optimal cooling and heating with lower energy consumption.
  • Inverter DC Technology: Rapidly achieves desired temperature and maintains efficient operation with wide-range frequency conversion.
  • All-Season Reliability: Operates in extreme conditions from 5°F to 125°F (-15°C to 52°C), ideal for various climates.
  • Outdoor Unit Heating Belt: Automatically activates below 32°F (0°C) to prevent freezing and conserve energy when temperatures rise.
  • I-Feel Technology: Built-in temperature sensor in the remote provides more accurate climate control based on your immediate environment.
  • I-Set Memory Function: Remembers your preferred settings for convenience on every startup.
  • 4-Way Auto-Swing Airflow: Vertical and horizontal swing eliminates hot/cold zones and promotes even air distribution.
  • Eco & Sleep Modes: Eco Mode boosts efficiency, while Sleep Mode maintains consistent temperature without overcooling or overheating.
  • Self-Cleaning Function: Quick-drying and sterilization reduces bacteria and mold buildup for a healthier home environment.
  • Easy-to-Clean Filter: Removable filter ensures optimal indoor air quality and hassle-free maintenance.
  • WiFi-Ready (Optional): Compatible with optional WiFi module for remote operation via smartphone or tablet.
  • Pre-Charged with R-410A Refrigerant: For quicker, more cost-effective installation.
  • Reliable Warranty Coverage: Backed by a 1-year parts/accessory and 5-year compressor limited warranty.

SPECIFICATIONS & DIMENSIONS

  • DIMENSIONS
  • Condenser Dimensions: 30.17" W x 10.63" D x 22.05" H
  • Air Handler Dimensions: 31.69" W x 7.87" D x 10.63" H
  • Condenser Weight: 71.64 lbs
  • Air Handler Weight: 17.64 lbs
  • CAPACITY & PERFORMANCE
  • Zone Capacity: 1
  • Cooling Capacity: 12,000 BTU
  • SEER2: 19
  • Heating Capacity: 12,500 BTU
  • Coverage Area: Up to 600 sq. ft.
  • Outdoor Operating Temperature : 5°F - 125.6°F (-15°C - 52°C)
  • Decibel (Sound) Rating: 36 dBA
  • ELECTRICAL REQUIREMENTS
  • Voltage: 115 V
  • Amperage: 19.2 A
  • Power Cable Included: No
  • REFRIGERANT & PIPING
  • Refrigerant Type: R-410A (Pre-Charged)
  • Line Set Length: 16.4 ft. (5 m) or 25 ft. (7.6 m)
  • FEATURES
  • Mount Type: Wall Mounted
  • Airflow Direction: 4-Way Auto Swing (Vertical & Horizontal)
  • Modes: Auto Mode // Cool Mode // Heat Mode // Dry Mode // Fan Mode
  • WiFi-Ready: (Optional) Compatible with optional WiFi module for remote operation via smartphone or tablet.
  • Inverter Technology: Yes (DC Inverter)
  • Remote Control Included: Yes
  • Self-Cleaning Function: Yes
  • Filter Type: Removable, Easy-Clean
  • CERTIFICATIONS & WARRANTY
  • Certifications: ETL Listed
  • Warranty: 5 Years Compressor & 1 Year Parts

INSTALLATION & GUIDES

File icon
User Manual PDF
File icon
WiFi Installation PDF
File icon
Troubleshooting & Error Codes PDF
