4th Gen New Release!

MRCOOL DIY Mini Split - 42,000 BTU 3 Zone Ductless Air Conditioner and Heat Pump, DIY-B-336HP121218

Name: MRCOOL DIY Mini Split - 42,000 BTU 3 Zone Ductless Air Conditioner and Heat Pump, DIY-B-336HP121218
Brand: MRCOOL
SKU: DIY-B-336HP121218
Price: 3979.0 USD
Availability: InStock

4.9 58 reviews

Model: DIY-B-336HP121218

$3,979.00

$3,979.00 ~~$4,449.00~~

-11%

Shipping calculated at checkout.

Financing Options

Product variants

This item is in stock! Estimated Arrival: Oct 17 to Oct 23

$3,979.00

$3,979.00 ~~$4,449.00~~

Product Overview

Zones: 3
DIY Installation
Voltage: 208-230V
Outdoor Operating Temp (Cool): 5°F to 122°F
Outdoor Operating Temp (Heat): -13°F to 75.2°F

What's Included

DESCRIPTION

This 4th Generation MRCOOL Mini Split includes a DIY 36,000 BTU Multi-Zone Condenser, two 12,000 BTU Wall Mounted Air Handler, one 18,000 BTU Wall Mounted Air Handler, and three Remotes. The best part about all of this is that you can install it yourself!

Package Includes

This package does not include linesets, don't forgot to scroll up and add them!

If all air handlers are run simultaneously, their combined BTU output will not exceed the BTU rating of the condenser. In this case, the combined BTU output of the Air Handlers will never exceed the 36K BTU Rating of the Condenser.

Condenser

Energy Efficient. This 4 Zone condenser, when paired with select MRCOOL air handlers, is capable of producing an impressive 21.5 SEER efficiency rating.
Works In All Environments. The capability to continue to deliver heating performance when temperatures reach -13°F
Lifetime Warranty. For added peace of mind, this is the only condenser on the market that comes with a limited lifetime compressor warranty. Simply register into the MRCOOL Care Program to get the lifetime warranty!

Air Handler, 12K BTU, Quantity 2

Large Coverage Area. Handler covers an area up to 500 sq. ft.
Versatile. Incredibly versatile and equipped with multiple operating modes, which include COOL, HEAT, AUTO, DRY (dehumidify), and SLEEP.
Easy to Control. This unit also has the capability to be controlled by your Apple or Android smartphone through the use of the Smart HVAC app.
Convenient Installation. With its light and compact design, it can be installed easily to most interior walls with the included mounting plate.

Air Handler, 18K BTU, Quantity 1

Large Coverage Area. Handler covers an area up to 750 sq. ft.
Versatile. Incredibly versatile and equipped with multiple operating modes, which include COOL, HEAT, AUTO, DRY (dehumidify), and SLEEP.
Easy to Control. This unit also has the capability to be controlled by your Apple or Android smartphone through the use of the Smart HVAC app.
Convenient Installation. With its light and compact design, it can be installed easily to most interior walls with the included mounting plate.

SPECIFICATIONS & DIMENSIONS

Condenser
Product Dimensions: 37.24"W x 16.14"D x 31.89"H
Cooling Capacity: 36,000 BTU
Heating Capacity: 36,000 BTU
Zone Capacity: 4
Cool Mode - Outdoor Operating Temperature Range: 5F ~ 122F
Heat Mode - Outdoor Operating Temperature Range: -13F ~ 75.2F
SEER: 21.5
EER: 10.5
Voltage: Requires a minimum of 208V-230V/60HZ/27-45A (please check your home meets this electrical requirement prior to purchase)
Registered Warranty: 7 Years Replacement on Compressor, 5 Years Parts
Air Handler 12K BTU
Product Dimensions: 31.57"W x 7.44"D x 11.69"H
Mount Type: Wall
Cooling Capacity: 12,000 BTU
Heating Capacity: 12,000 BTU
Registered Warranty: 5 Years Parts
Modes: Auto - auto selects from Cool, Heat or Fan-Only // Dry - dehumidify // Cool // Heat // Fan Only // Quiet // Sleep
Air Handler 18K BTU
Product Dimensions: 42.52"W x 8.90"D x 13.19"H
Mount Type: Wall
Cooling Capacity: 18,000 BTU
Heating Capacity: 18,000 BTU
Registered Warranty: 5 Years Parts
Modes: Auto - auto selects from Cool, Heat or Fan-OnlyDry - dehumidifyCoolHeatFan OnlyQuietSleep

INSTALLATION & GUIDES

Installation Manual
Product Brochure
Performance Specifications
Warranty
Energy Guide
AHRI Certificate

COVERAGE AREA

Please refer to this coverage chart to determine how many BTUs are required for the area you would like to cool or heat.

BTU	Square Feet
9,000 BTU	180 - 375 Sq Ft.
12,000 BTU	376 - 500 Sq Ft.
18,000 BTU	501 - 750 Sq Ft.
24,000 BTU	751 - 1,000 Sq Ft.
36,000 BTU	1,001 - 1,500 Sq Ft.

Some additional factors may impact performance such as insulation, ceiling height and the number of appliances in the room. For assistance, contact our Product Experts.
