MRCOOL 24K BTU Downflow Two-Stage Heat Pump - Left Return, GCHPD024TGTANXL
This item is in stock! Estimated Arrival: May 08 to May 14
-
Free
Shipping -
30-Day
Returns* -
Authorized
Dealer -
Professional
Services
Exclusive Offers Just For You!
🔨Angi: Enjoy affordable installation services across the country. Schedule Now!
🚚 1-800-GOT-JUNK: 10% discounts on haul away services for your outdated appliances. Request a Quote Today!
Have a question or want to build your own package?
Talk with one of our trusted appliance experts today!
24K BTU Downflow Two-Stage 230V 1-Phase 60Hz CuNi Coil Left Return
Features:
- Qualifies for federal tax credit, and other incentives
- Highest energy efficiency in its class
- Safety high and low pressure switches
- Quiet operation
- Full featured sinusoidal eon motor control technology
- Insulated sloped stainless steel drain pan
- Advanced unit control board with diagnostic LEDs
- Double O-ring water connections
- Easy service access
- Optional domestic water pre-heating
- Made in the USA
- 10 year compressor warranty
| Product Dimensions | 25.75"W x 32"D x 56"H |
| Product Weight | 325 lbs |
| EER | Ground Water (FULL) 27.40 / Ground Loop (FULL) 17.95 |
| EER Part Load | Ground Water (PART) 36.50 / Ground Loop (PART) 25.93 |
| COP 47 | Ground Water (FULL) 5.40 / Ground Loop 4.20 (FULL) |
|
COP 47 Part Load |
Ground Water (PART) 5.50 / Ground Loop 4.70 (PART) |
| HSPF | Ground Water Fluid Flow Rate | COOLING: (PART) 7 - 8 (FULL) / HEATING: (PART) 7 - 8 (FULL) |
| AFUE | Ground Loop Fluid Flow Rate | COOLING: (PART) 7 - 8 (FULL) / HEATING: (PART) 7 - 8 (FULL) |
| CFM | COOLING (PART) 850 - 1000 (FULL) / HEATING (PART) 800 - 950 (FULL) |
| Tonnage | 2 |
| Cooling Capacity | Ground Water (PART) 23000 - 29000 (FULL) / Ground Loop (PART) 21900 - 27000 (FULL) |
| Heating Capacity | Ground Water (PART) 19000 - 25700 (FULL) / Ground Loop (PART) 16500 - 18500 (FULL) |
| Voltage | 230V/60Hz/34A |
| Phase | 1 |
| Cycle | 60 |
| Stage | Two-Stage |
| Max Fuse Breaker | 34.0 (W/O Desupe |
| Min Circuit Ampacity | 21.9 |
| Configuration | Left Return Downflow |
| Color | Gray |
| Max Coverage Area | 1000 |
| Refrigerant Type | R-410A |
| Compressor Motor Type | Scroll |
| Blower Motor Type | Axial Flux (No Shaft) BLA |
| Blower Motor HP | 3/4 |
| Filter Type | Replaceable |
| Contains | Electronics Chemicals Aerosol Compressed Gas |
| Proposition 65 Warning | Yes |
| Certifications | ETL Listed Energy Star AHRI |
| Warranty | Registered 10 Year Parts Warranty |
