Luxury meets attainable with the ZLINE 48” 6.7 cu. ft. 8 Burner Double Oven Gas Range in Stainless Steel. Crafted with a commitment to both modern style and functional excellence, this professional gas range offers a sophisticated culinary experience for home chefs.

Italian-Made Auto-Reignition Burners
8 Italian-made gas burners effortlessly ignite and automatically reignite for enhanced temperature control and safety.

Dual Function Burner
Experience versatility with a single Dual Function Burner, allowing simmering at 1,000 BTUs or perfect searing at 20,000 BTUs.

Convection Gas Oven
Standard bake, broil, and convection bake modes with a BTU output of 22,000 elevate your culinary endeavors.

Large Oven Capacity
A spacious 6.7 cu. ft. oven (4.2 cu. ft. + 2.5 cu. ft.) accommodates pans up to 20 inches wide, providing maximum space for everyday cooking.

StayPut Oven Door Hinges
Designed to support the full weight of the oven door, offering additional convenience and safety.

Premium Oven Insulation
3-layered glass and aluminum mesh seal for superior heat retention and consistent temperatures, ensuring perfect dishes every time.

Smooth Glide Ball-Bearing Oven Racks
Durable ball-bearing oven racks provide extra convenience and ease when handling larger dishes.

Dual Oven Lights
Illuminate your oven space with dual halogen lighting, controlled by a switch on the front control panel.

Professionally Crafted
Crafted with 430-grade stainless steel and durable cast iron grates that exceed industry standards for a true professional experience.

Minimal Cleaning
Hand-finished porcelain one-piece cooktop allows for easy cleaning and maintenance.

LP Conversion Kit
Equipped with an LP conversion kit for versatility in converting from natural gas to liquid propane (must be done by a professional).

Manufacturer Warranty
Backed by a 1-year parts and service warranty for added peace of mind. Limited lifetime warranty on ZLINE Italian burners includes part replacements for burners and burner caps, and parts and labor for spark tips if proven defective in materials or workmanship.

ZLINE 46" Width Wall Mount Range Hood Insert (18" Depth), 698-46

OPTIONS & ACCESSORIES

Ductless/Recirculate Option - No
Crown Molding(s) - NA
Certified Outdoor Use - No
Also available in 28"(698-28), 34"(698-34), 40"(698-40)

PRODUCT DESCRIPTION:

The ZLINE 698-46 is a 46-inch professional range hood insert designed to be both elegant and powerful, featuring the industry's only lifetime warranty motor. This hood is made from 430-grade stainless steel and is a ZLINE classic. Its durable construction, modern design, and lifetime warranty motor - a ZLINE exclusive - guarantee a range hood with a timeless design that will last a lifetime.

This hood contains many unique features, such as:
• Dishwasher-safe stainless steel baffle filters
• Built-in LED lighting
• High performance 4-speed motor with speeds up to 700 CFM

All ZLINE range hoods are ETL Listed and come equipped with everything needed to easily install and use.

ZLINE is the industry leader in range hoods and stands by the quality and longevity of their stainless steel range hoods. The 698-46 ships next business day when in stock.

PRODUCT SPECIFICATIONS:

Brand:	ZLINE Kitchen and Bath
Dimension:	46" W x 18" D x 14.2" H
Venting Size:	8" Outlet (Transition piece to round ducting included)
Airflow (Q/L/M/H):	280/460/670/700 (CFM)
Lighting:	4 Directional LED Lights (3-Watt)
Noise Level:	30/42/51/56 (Decibels)
Voltage:	110V/60HZ
Motor:	High Performance 700 CFM/4-Speed Dual Motor
Mount Type:	Range Hood Insert (For Wall Mount Hoods)
Speeds:	4 speeds
Control Type:	Speed/Timer Panel with LCD (3 Minute AutoTimer with Delayed Shutoff)
Filters:	Stainless Steel Baffle Filters (Dishwasher Safe)
Material:	21g #430 Stainless Steel
Warranty:	3 Year Parts Warranty
Features:	Model No. 698-46 (ETL Listed)
UPC:	855187005085
Certifications:	ETL Certified

INSTALLATION INSTRUCTIONS

Range Hood Decibel Levels:

ZLINE Range Hoods are supposed to be seen, not heard. That’s why even at the highest speed our range hoods only reach 56 decibels, which is quieter than your average conversation. Rest assured that your new range hood will not be interrupting your dinner party or when you’re helping with homework.

Chimney Sizing:

ZLINE Range Hoods are designed to fit the majority of kitchens right out of the box. Some kitchens with shorter ceilings do need a shortening kit or an extension kit depending on ceiling height. All our stainless steel hoods come with two telescoping chimneys to ensure the perfect fit. For our Designer Series hoods, we provide a one-piece chimney that can be cut to size.



This ZLINE Professional 36" 22.5 cu. ft Freestanding French Door Refrigerator, crafted in Lake Tahoe, USA, combines top-tier performance with classic design. This refrigerator is packed with innovative features to enhance your kitchen experience, making it the perfect blend of style and functionality.

• Built-in Ice Maker: Enjoy the convenience of an automatic ice maker that produces up to 4.85 lbs of ice daily, with easy access to up to 1.75 lbs of stored ice.
• Spacious Interior: With a generous 22.5 cu. ft. capacity and two large freezer drawers, you’ll have plenty of space to keep your groceries organized and within reach.
• Counter Depth Design: Achieve a sleek, modern kitchen look with a fridge that fits perfectly flush with your countertops.
• Customizable Temperature Control: Adjust the refrigerator temperature between 34°F to 44°F and freezer settings from -7°F to 7°F, ensuring your food is stored in the ideal environment.
• RapidChill Mode: Need to cool something quickly? Use the RapidChill mode to save time and keep your food fresh.
• Digital ChillControl: Easily manage temperatures and switch between modes—vacation, sabbath, or eco—using the intuitive LED display.
• CrispControl Drawer: Keep fruits and vegetables fresh longer with two adjustable temperature crisper drawers.
• Dual Cooling System: Separate cooling systems for the refrigerator and freezer ensure optimal freshness and prevent odors from mixing.
• Fingerprint-Resistant Finish: Keep your fridge looking spotless with our smudge-proof, fingerprint-resistant stainless steel finish.
• Energy Efficient: ENERGY STAR rated for superior insulation and an energy-reducing cooling system, combining power with savings.

*Assembly Required: This refrigerator and its door handles will ship in multiple boxes and requires assembly upon installation.

User Manual
Installation Manual

ZLINE 24 in. Top Control Tall Dishwasher in Stainless Steel with 3rd Rack, DWV-304-24

Experience Attainable Luxury with the ZLINE Tall Tub Top Control Dishwasher in Stainless Steel. Featuring 8 different wash cycles to accommodate every need, this dishwasher delivers a powerful performance with sparkling clean and dry dishes every time. Customize the dishwasher to your needs with two adjustable racks and a third utensil rack for added flexibility. This ENERGYSTAR Certified dishwasher is designed to optimize performance with every use, using multiple filter technology that ensures clean dishes while being environmentally friendly. Choosing a ZLINE dishwasher means you've chosen a product that is high performance, professional quality, energy conscious, and fully customizable to your kitchen.

The ZLINE DWV-304-24 includes a Stainless Steel panel and ships next day when in stock. This dishwasher will be sent in multiple boxes.

DESIGN & PERFORMANCE

• ZLINE Stainless Steel Finish Panel
• At only 51 decibels of sound on the highest setting, ZLINE dishwashers will let your kitchen tasks continue in peace.
• All installation hardware included - One of the easiest in the industry, guaranteed!
• Top control panel is easy and straightforward to use, while offering a sleek concealed look

INSTALLATION & CARE

• Simple Installation - This dishwasher comes with a single three prong plug for easy installation
• Below is a video on how to install a custom panel:

Information Center:

• Ultimate Dishwasher Guide: 5 things to consider when buying a Dishwasher: Read Now

Installation Manual
